Reinhausen RMT-1 Contact Kit
A precision replacement contact kit for the Reinhausen RMT-1 transfer, reverse, and selector switch, machined to OEM dimensional specifications.
- OEMReinhausen
- Model / SeriesRMT-1
- Part typeKit
- EquipmentLoad tap changers (LTCs)
- AvailabilityBuilt to order / lead time confirmed at quote
- Internal ref.LTC-RE-RMT1-KIT
Overview
Full contact kit for the Reinhausen RMT-1 transfer, reverse, and selector switch: reversing, transfer, and selector switch contacts plus front and back collector rings. Thirteen line items, 80 pieces per complete kit.
About the Reinhausen RMT-1 Switch
The Reinhausen RMT-1 is a transfer, reverse, and selector switch used in load tap changers on utility transformers. Its transfer, reversing, and selector switch contacts are the primary wear components at maintenance intervals. Southern Switch machines OEM-spec replacement contacts for the RMT-1 and reverse-engineers discontinued parts from a sample, a drawing, or a model number.
Why replace worn LTC contacts
Worn or burned tap-changer contacts raise resistance, run hot, and can lead to tap-changer failure. Precision replacements restore reliable switching and extend the service life of the LTC.
Stock, lead time & reverse engineering
Lead time is confirmed at quote; discontinued or hard-to-find parts are reverse-engineered from a sample, a drawing, or a model number. Based in Palm Harbor, FL, Southern Switch & Contacts manufactures and ships replacement parts to utilities nationwide, and has served the industry since 1982.
The complete Reinhausen RMT-1 contact kit covers thirteen line items, 80 pieces per complete kit. Quantities shown are per complete kit. Contact us for pricing and lead time.
What’s in the kit
Every part below ships in the kit, listed with its OEM number and the quantity per kit. Need only certain parts or quantities? Tell us and we will tailor the quote.
| Ref | Description | Qty |
|---|---|---|
| 1 | Reverse Switch Moving Arm Assembly | 3 |
| 2 | Reverse Switch Contact "R" | 3 |
| 3 | Reverse Switch Stationary Contact | 6 |
| 4 | Selector Switch Stationary Contact (OEM 261D146 H08) | 27 |
| 5 | Back Collector Ring | 3 |
| 6 | Selector Switch Moving Assembly (OEM 770B443 G01) | 3 |
| 7 | Transfer Switch Moving Arm Bracket (OEM 785C156 H04) | 6 |
| 8 | Transfer Switch Stationary Contact Assembly (OEM 4421A39 H01) | 6 |
| 9 | Transfer Switch Movable Contact (OEM 261D146 H05) | 6 |
| 10 | Transfer Switch Stationary Arcing Contact (OEM 231C471 G02) | 6 |
| 11 | Transfer Switch Moving Arcing Contact (OEM 475C858 G01) | 6 |
| 12 | Front Collector Ring | 3 |
| 13 | Inspection Door Gasket | 2 |
Worn but not scrap? Send us your used contacts. We recondition them to OEM dimension, or machine a new set from your sample, and return them tested and documented. Often cheaper and faster than buying new.
Send the model number, asset tag, or just a description, we’ll reply with pricing and lead time within one business day.
Net 30 with an accepted PO, no credit application required. How we do business →
